Commutateur Aruba JL683B Instant On 1930 24G Class4 PoE 4SFP/SFP+ 195W à Londres, Royaume-Uni

The JL683B is the newer hardware revision. The primary upgrade is improved acoustic performance. While the "A" model could be audible in a quiet room, the "B" revision uses a redesigned fan profile and more efficient cooling to operate at significantly lower decibel levels (approx. 25.8 dB at idle/low load), making it "nearly silent" for desk-side use.

Yes. The JL683B provides 24 Gigabit Ethernet ports with Class 4 PoE, allowing compatible devices such as Wi-Fi access points, IP cameras and VoIP phones to receive power and data through a single Ethernet cable. Its total PoE power budget is 195W.

Yes. The switch has four SFP+ uplink ports supporting 1GbE and 10GbE connections. Using compatible transceivers or direct-attach cables, you can connect it to a 10GbE core switch or supported server for higher-speed network links.

Yes. The switch supports management through the Instant On mobile app and web portal, with no recurring subscription required for standard management. It also provides a local web interface for configuration and monitoring.

Yes. The JL683B can power compatible PoE IP cameras and connect them to a central network. Its 24 Gigabit ports and 195W PoE budget make it suitable for many small and medium-sized CCTV deployments. Check the combined power requirements of all cameras and other PoE devices before installation.

Both models offer 24 Gigabit PoE ports and four SFP+ uplinks supporting up to 10GbE. The main difference is the available PoE power budget: the JL683B provides 195W, while the JL684B provides 370W. Choose the JL684B if your access points, cameras and phones require a higher combined power budget.

Yes. The JL683B features 4 dedicated SFP+ ports that support 10Gbps speeds. This is ideal for connecting to a high-speed server, a NAS, or as a "backbone" link to another switch in a multi-floor London office.

Class 4 PoE allows each PoE port to deliver up to 30 W of power, which is ideal for powering devices like access points, VoIP phones, and cameras without needing separate power adapters.

You can manage it using the Aruba Instant On cloud portal, mobile app (iOS/Android), local web GUI, or SNMP, giving remote access and monitoring capabilities.

Yes — it supports VLANs, access control lists (ACLs), and advanced Layer 2 features to segment and secure network traffic.

Absolutely — with PoE+, fiber uplinks, and smart management, it’s ideal for environments that require reliable, secure, and high-performance wired networking.

This switch is backed by a Limited Lifetime Warranty with phone support and chat support options throughout the warranty duration.

It is a Layer 2+ switch, meaning it handles standard switching plus Static IPv4 Routing. This allows the switch to handle internal traffic routing between different VLANs (e.g., separating your Guest Wi-Fi from your Office Servers) without needing to send that data back to your main router, which speeds up the network.
